1.65MHz 4.8V Ultrasonic Atomizing Transducer For Humidifier Board

1.65MHz 4.8V Ultrasonic Atomizing Transducer For Humidifier Board

1.65MHz 4.8V Ultrasonic Atomizing Transducer For Humidifier Board
1.65MHz 4.8V Ultrasonic Atomizing Transducer For Humidifier Board

Large Image :  1.65MHz 4.8V Ultrasonic Atomizing Transducer For Humidifier Board Get Best Price

Product Details:

Place of Origin: Jiangsu, China
Brand Name: YUJIE
Certification: ISO9001
Model Number: HJ-3835

Payment & Shipping Terms:

Minimum Order Quantity: 1000 Piece/Pieces
Price: Negotiable
Packaging Details: Carton
Delivery Time: 3~30 working days
Payment Terms: T/T, Western Union
Supply Ability: 200000 Piece/Pieces per Month
Detailed Product Description
Type: Piezoelectric Ceramics Material: PZT
Surface Plating: Glaze Port: Shenzhen
High Light:

ultrasonic atomizing piezoelectric transducer

,

piezo element

Ultrasonic Atomizing Transducer Of 1.65MHz 4.8V For Humidifier Board

  1.65MHz 4.8V Ultrasonic Atomizing Transducer For Humidifier Board 0

Direction : (1,2,3,……17,18,19 Red mark)

1,2,3 : Adjust the Atomizing

4,5 : Working pilot lamp

6,7 : Reed switches with the water level

8,11 : Power pilot lamp

9,10 : Fuse

12,13 : AC 48V Atomizing input power supply

14,15 : AC 12V Fan input power supply

16,17 : DC 12V Fan output power supply

18,19 : Atomizing

********** Drive condition: Import Voltage 48v AC

Import current: 0.75A

Water level: 43mm

Fog output: 400ml/h



Apply φ25mm,1.65MHZ crystal and big audion

Voltage:AC48V/0.5A    Power:24W

Water level :25-35mm   Fog output:400±100ml/h
